48
1. Undock your OmniBook.
2. Adjust each tilt foot to a comfortable height by squeezing the edges of the foot and
sliding it until it clicks into a secure position.
To install an ISA card
You can add up to two ISA cards, such as network (LAN) cards, to the docking system.
C A U T I O N Before removing the card from its bag, equalize static electricity by touching the
bag and the port replicator’s metal back plate at the same time.
Handle the card by its edges. Avoid touching electronic components.
1. Undock the OmniBook and unplug the ac adapter from the docking system.
2. Remove the cable cover.
3. Slide the metal shield from the base.
If the shield is difficult to slide, you can insert a pen or small screwdriver into the
gap between the shield and base and gently work the shield loose. Be sure to loosen
the shield evenly on both the right and left sides before attempting to remove it.
Installing an ISA
Card
