HP Data Vault User's Guide
Hardware Status Levels
Green Yellow Red
Fan Speed Greater than or equal to
800 rpm Between 600 rmp and
800 rpm Less than 600 rpm
Temperature (PECI) Less than 85 Between 85 and 100 Greater than or equal to
100
3.3V Between 3.069V and
3.531V 7-10% greater or lesser
than 3.3V More than 10% greater
or lesser than 3.3V
5.0V Between 4.650V and
5.350V 7-10% greater or lesser
than 5.0V More than 10% greater
or lesser than 5.0V
12.0V Between 10.200V and
13.800V 15-20% greater or
lesser than12.0V More than 20% greater
or lesser than 12.0V
5. Click OK.
84
