Meta Data Usage Rate
Function
The meta data usage rate of the current journal is shown, with journal volume meta data space
assumed to be 100%.
Storing period
Short-Range can be specified.
Selection of monitoring objects
Select the desired monitoring objects in the Performance Objects field.
Item on right side of Monitor Data
field Item on left side of
Monitor Data field Item on right side of
Object field Item on left side of
Object field
Meta Data Usage Rate (%) Master Journal Cnt Ac-J/Cnt Ac-J Z Journal
Meta Data Usage Rate (%) Restore Journal
Detailed information of resources on top 20 usage rates
Function
You can view resources of the 20 most-used MP blades. The system puts in order of use 20 MP
blades based on rates collected during the most recent usage period. You cannot specify a particular
period.
Storing period
Only the Short-Range real time monitoring data can be supported.
Selection of monitoring objects
Select the desired monitoring objects in the Performance Objects field.
Item on right side of Monitor
Data field Item on left side of Monitor
Data field Item on right side of Object
field Item on left side of Object
field
None Usage Rate (%) MP Controller
Viewing MP blade resource details
To view the resources assigned to an individual MP blade, click the link to the name of the MP
blade in the right panel of the Monitor window. The MP Properties window lists the 20 most-used
resources by blade name.
Meta Data Usage Rate 43
