Syntax – HP XP7 Storage User Manual
Page 106
Table 7 Operands of the group subcommand and saved monitoring data (continued)
See
Saved ZIP file
Monitoring data saved in
the file
GUI operation
Operand
UniversalReplicator.ZIP
Statistics about remote
copy operations by
Select Entire Storage
System Cnt Ac-J/Cnt
UniversalReplicator
Continuous Access Journal
Ac-J Z from Object list
and Continuous Access
in Performance Objects
Journal Z (for entire
volumes)
field in Monitor
Performance window
URJNL_dat.ZIP
Statistics about remote
copy operations by
Select Journal from
Object list in
URJNL
Continuous Access Journal
Performance Objects
and Continuous Access
Journal Z (for journals)
field in Monitor
Performance window
URLU_dat.ZIP
Statistics about remote
copy operations by
Select LUN Cnt Ac-J/Cnt
Ac-J Z from Object list
URLU
Continuous Access Journal
in Performance Objects
and Continuous Access
field in Monitor
Performance window
Journal Z (for each volume
(LU))
URLDEV_dat/URLDEV_XXXXX.ZIP
5
Statistics about remote
copy operations by
Continuous Access Journal
Select Logical Device
Cnt Ac-J/Cnt Ac-J Z
from Object list in
URLDEV
and Continuous Access
Performance Objects
Journal Z (for volumes
field in Monitor
Performance window
controlled by a particular
CU)
PhyMPPK_dat.ZIP
MP usage rate of each
resource allocated to MP
blades
Select MPPK from
Object list in
Performance Objects
PhyMPPK
field in Monitor
Performance window.
Notes:
1
When you specify the PhyPG, PhyLDEV, PhyProc, or PhyCMPK operand, you can select the storing period of the
monitoring data to be exported from short range or long range. When you specify other operands, the monitoring
data in short range is exported.
2
A ZIP file name beginning with PhyExLDEV_.
3
A ZIP file name beginning with RCLDEV_.
4
A ZIP file name beginning with URLDEV_.
You can use the group subcommand more than one time in a command file. For example, you
can write the following script:
group PortWWN CL1-A:CL1-B
group RemoteCopy
If an operand is used more than one time in a command file, the last operand takes effect. In the
example below, the first group subcommand does not take effect, but the second group
subcommand takes effect:
group PortWWN CL1-A:CL1-B
group PortWWN CL2-A:CL2-B
Syntax
group {PhyPG [Short|Long] [parity-group-id]:[parity-group-id]][…]|
PhyLDEV [Short|Long] [parity-group-id]:[parity-group-id]][…]|
PhyExG [[exg-id]:[exg-id]][…]|
PhyExLDEV [exg-id]:[exg-id]][…]|
106 Exporting Performance Monitor data
