Short Range indicates the storing period and sampling interval of the monitoring data stored
in short range. Long Range indicates those of the monitoring data stored in long range. When
you run the Export Tool, you can export the monitoring data within these periods into files. If you
use the short-range or long-range subcommand additionally, you can narrow the term of
data to be exported (see
“Short-range” (page 113) or “long-range” (page 115) ).
From indicates the starting time for collecting monitoring data. To indicates the ending time for
collecting monitoring data.
Interval indicates the interval at which the monitoring data was collected (sampling interval).
For example, Interval 15min. indicates that monitoring data was collected at 15-minute
intervals.
group
Description
The group subcommand specifies the type of monitoring data that you want to export. This
command uses an operand (for example, PhyPG and PhyLDEV above) to specify a type of
monitoring data.
Table 7 (page 104) shows the monitoring data that can be saved into files by each operand, and
the saved ZIP files. For details on the monitoring data saved in these files, see the tables listed in
the See column.
Table 7 Operands of the group subcommand and saved monitoring data
See Saved ZIP file Monitoring data saved in
the file GUI operation Operand
Table 9 (page 123) PhyPG_dat.ZIP
1
Usage statistics about
parity groups Select Parity Groups
from Object list in PhyPG
Performance Objects
field in Monitor
Performance window.
PhyLDEV_dat.ZIP
1
Usage statistics about
volumes Select Logical
Device/Base from PhyLDEV
Object list in
PhyExG_dat.ZIP Usage conditions about
external volume groups PhyExG Performance Objects
field in Monitor
Performance window.
PhyExLDEV_dat/PHY_ExLDEV_XXXXX.ZIP
2
Usage conditions about
external volumes PhyExLDEV
PhyProc_dat.ZIP
1
Usage statistics about MPs
and data recovery and
reconstruction processors Select Controller from
Object list in
Performance Objects PhyProc
field in Monitor
Performance window.
PhyCMPK_dat.ZIP
1
Usage statistics about
access paths, write
pending rate, and cache Select Access Path from
Object list in
Performance Objects PhyCMPK
field in Monitor
Performance window.
Table 10 (page
125) PG_dat.ZIP Statistics about parity
groups, external volume
groups Select Parity Group
from Object list in
Performance Objects PG
field in Monitor
Performance window.
Table 11 (page
127) LDEV_dat/LDEV_XXXXX.ZIP
3
Statistics about volumes in
parity groups, in external
volume groups Select Logical Device
from Object list in
Performance Objects LDEV
