Table 14 Files with statistics about mainframe ports
Data saved in the file CSV file ZIP file
The number of read and write operations per second measured at every
port MF_Port_IOPS.csv MF_Port_dat.ZIP
Response time per port (in microseconds) MF_Port_Response.csv
Read/write data transfer amount per port (in KB/sec) MF_Port_Read_Write_KBPS.csv
Read data transfer amount per port (in KB/sec) MF_Port_Read_KBPS.csv
Write data transfer amount per port (in KB/sec) MF_Port_Write_KBPS.csv
Average CMR processing time (in microseconds) MF_Port_Avr_CMR.csv
Average disconnection time (in microseconds) MF_Port_Avr_DisconnectTime.csv
Average connection time (in microseconds) MF_Port_Avr_ConnectTime.csv
Number of open exchanges per second MF_Port_Avr_OpenExchange.csv
Host bus adapters connected to ports statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be exported to files using the Export Tool. These files contain statistics about host
bus adapters connected to ports.
Table 15 Files with statistics about host bus adapters connected to ports
Data saved in the file CSV file ZIP file
The I/O rate (that is, the number of read and write operations per
second) for HBAs that are connected to a port PortWWN_xx_IOPS.csv PortWWN_dat.ZIP
The size of data transferred per second (KB/sec) between a port
and the HBAs connected to that port PortWWN_xx_KBPS.csv
The average response time (microseconds) between a port and
the HBAs connected to that port PortWWN_xx_Response.csv
Notes:
•
The letters "xx" in CSV filenames indicate a port name. For example, if the filename is PortWWN_1A_IOPS.csv,
the file contains the I/O rate for each host bus adapter connected to the CL1-A port.
•
If files are exported to a Windows computer, CSV filenames may end with numbers (for example,
PortWWN_1A_IOPS-1.csv and PortWWN_1a_IOPS-2.csv).
Volumes (LU) statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be exported to files using the Export Tool. These files contain statistics about
volumes (LUs).
Table 16 Files with statistics about volumes (LUs)
Data saved in the file CSV file ZIP file
The number of read and write operations per second LU_IOPS.csv LU_dat.ZIP
The size of data transferred per second (KB/sec) LU_TransRate.csv
The size of read data transferred per second (KB/sec) LU_Read_TransRate.csv
The size of write data transferred per second (KB/sec) LU_Write_TransRate.csv
The average read response time (microseconds) LU_Read_Response.csv
130 Exporting Performance Monitor data
