Table 7 Operands of the group subcommand and saved monitoring data (continued)
See Saved ZIP file Monitoring data saved in
the file GUI operation Operand
field in Monitor
Performance window.
Table 12 (page
128) LDEVEachOfCU_dat/LDEV_XXXXX.ZIP
3
Statistics about volumes in
parity groups or in external
volume groups (for volumes Select Logical
Device/Base from
Object list in LDEVEachOfCU
controlled by a particular
CU) Performance Objects
field in Monitor
Performance window.
Table 13 (page
129) Port_dat.ZIP Statistics about ports Select Fibre Port from
Object list in Port
Performance Objects
field in Monitor
Performance window.
Table 14 (page
130) MF_Port_dat.ZIP Mainframe fibre ports Select Fibre Port from
Object list in MFPort
Performance Objects
field in Monitor
Performance window.
Table 15 (page
130) PortWWN_dat.ZIP Statistics about host bus
adapters connected to
ports Select WWN from
Object list in
Performance Objects PortWWN
field in Monitor
Performance window.
Table 16 (page
130) LU_dat.ZIP Statistics about LUs Select LUN/Base from
Object list in LU
Performance Objects
field in Monitor
Performance window.
Table 17 (page
131) PPCGWWN_dat.ZIP All host bus adapters that
are connected to ports Select WWN from
Object list in PPCGWWN
Performance Objects
field in Monitor
Performance window.
Table 19 (page
132) RemoteCopy_dat.ZIP Statistics about remote
copy operations by Select Entire Storage
System Cnt Ac-S/Cnt RemoteCopy
Continuous Access Ac-S Z from Object list
Synchronous and in Performance Objects
Continuous Access field in Monitor
Performance window
Synchronous Z (in complete
volumes)
Table 20 (page
133) RCLU_dat.ZIP Statistics about remote
copy operations by Select LUN Cnt
Ac-S/Cnt Ac-S Z from RCLU
Continuous Access Object list in
Synchronous and Performance Objects
Continuous Access field in Monitor
Performance window
Synchronous Z (for each
volume (LU))
Table 21 (page
133) RCLDEV_dat/RCLDEV_XXXXX.ZIP
4
Statistics about remote
copy operations by Select Logical Device
Cnt Ac-S/Cnt Ac-S Z RCLDEV
Continuous Access from Object list in
Synchronous and Performance Objects
Continuous Access field in Monitor
Performance window
Synchronous Z (for volumes
controlled by a particular
CU)
Export Tool command reference 105
