When you connect XP24000 and XP12000 disk arrays, you may specify as shown in
Table 21 (page 49) .
Table 21 Range You Can Specify when You Connect XP24000 and XP12000 disk arrays
XP12000 disk array 1, 2 XP24000 disk array 1 Restriction Item
From 1A to GR From 1A to GR Port number
From 0000 to 03FF From 0000 to 03FF LUN
From 00:00 to 3F:FF From 00:00:00 to 00:3F:FF LDKC
3
:CU:LDEV
1 It does not affect to the value whether the model connects as MCU or RCU.
2 To connect to the XP12000 disk arrays, the microcode version of the storage system must be 50-09-37-xx/xx or later.
3 LDKC number is applied only to the XP24000 disk array.
