FS status Cnt Ac-S/Cnt Ac-J task
PSUE RCPY PSUS, PFUS PAIR, PFUL COPY
Remote storage: Remote storage system
The following table shows the Cnt Ac-S/Cnt Ac-J tasks when the FS P-VOL is shared with a Cnt
Ac-S/Cnt Ac-J S-VOL.
FS status Cnt Ac-S/Cnt Ac-J task
PSUE RCPY PSUS, PFUS PAIR, PFUL COPY
No No No No No Create pair
Yes N/A Yes Yes Yes Split pair
Yes N/A Yes Yes Yes Resynchronize pair
Yes N/A Yes Yes Yes Delete pair
Yes N/A Yes Yes Yes Switch to remote storage
*Use a Cnt Ac-S/Cnt Ac-J S-VOL as an FS P-VOL.
For more information about using Cnt Ac-S/Cnt Ac-J S-VOL as an FS P-VOL, see “Workflow for sharing volumes with
Continuous Access Synchronous or Continuous Access Journal” (page 72) .
Legend
Yes: You can perform the task
No: You cannot perform the task (the command is rejected)
N/A: Not applicable
Volume backup in a 3DC multi-target configuration workflow
You can use FS to back up Cnt Ac-S and Cnt Ac-J volumes on the remote sites in a 3DC multi-target
configuration.
The following figure shows how to back up the volumes.
•
Pair 1 is a Cnt Ac-S pair.
•
Pair 2 is an Cnt Ac-J pair.
•
Pair 3 is an Cnt Ac-J pair for delta resync.
•
Pairs 4, 5, and 6 are FS pairs.
You must create 3DC multi-target and delta resync pairs (pairs 1, 2, and 3) before creating pairs
5 and 6, but not before creating pair 4.
You cannot share 3DC volumes that use two mirrors with FS.
