Selected Pairs table
The following table lists the items in this table in the Select Secondary Volumes window of the
Create Pairs wizard.
Description Item
The P-VOL information. Primary Volume
Values:
•
LDEV ID: The P-VOL's LDEV identification number.
•
LDEV Name: The P-VOL's LDEV name.
• Port ID: The port name of the P-VOL LDEV's LUN path.
FS and BC/SS only.
• Host Group Name: The host group name of the P-VOL LDEV's LUN path.
FS and BC/SS only.
•
LUN ID: The LUN ID of the P-VOL LDEV's LUN path.
FS and BC/SS only.
•
Capacity: The P-VOL's volume capacity.
The snapshot group name. Snapshot Group
Indicates whether the snapshot group is new or existing. New Snapshot Group
Values:
• Yes: Newly created snapshot group.
•
No: Already defined snapshot group.
The S-VOL information. Secondary Volume
Values:
• LDEV ID: The S-VOL's LDEV identification number.
If you have not allocated an LDEV to the S-VOL, this item is blank.
•
LDEV Name: The S-VOL's LDEV name. If you have not allocated an LDEV to
the S-VOL, a hyphen (-) is shown.
• Port ID: The port name of the S-VOL LDEV's LUN path.
FS and BC/SS only.
•
Host Group Name: The host group name of the S-VOL LDEV's LUN path.
FS and BC/SS only.
•
LUN ID: The LUN ID of the S-VOL LDEV's LUN path.
FS and BC/SS only.
• Capacity: The S-VOL's volume capacity.
The volume’s copy type. Copy Type
Values:
•
FS: FS pair
The pool name and identification number. Pool Name (ID)
Click to remove the unwanted pairs or LDEV from the Selected Pairs table. Remove button
Confirm window
This window is the fourth and last window of the Create Pairs wizard.
The following image shows this window.
182 Fast Snap GUI reference
