C
REATING
HP EFS WAN A
CCELERATOR
R
EPORTS
AND
L
OGS
To create the Link
State report
1. Click the Reports tab to display the Performance - Bandwidth Optimization page.
2. Under Network in the left menu, click Link State to display the Network - Link
State page.
Figure 3-15. Network - Link State Page
3. Use the controls to customize the report, as described in the following table..
Control
Description
Period
Select Last Hour, Last Day, Last Week, or Last Month from the drop-down list.
Statistic
Select Loss Rate from the drop-down list.
Peer
Select All or a specific peer from the drop-down list.
Refresh
Set a rate to refresh the report display:
• To refresh your report every 15 seconds, click 15 Seconds.
• To refresh your report every 30 seconds, click 30 Seconds.
• To turn off refresh, click Off.
NOTE: The refresh rate does not affect polling. Polling occurs every 5 minutes.
Printer icon
To print your report, click the Printer icon in the upper right corner of the page.
