and/or secondary sites.
describes the host pair status reporting for Universal
Replicator for Mainframe volumes, ShadowImage for Mainframe volumes, and Universal Replicator
for Mainframe/ShadowImage for Mainframe shared volumes.
shows the
currency of the data on a shared Universal Replicator for Mainframe/ShadowImage for Mainframe
volume based on the Universal Replicator for Mainframe and ShadowImage for Mainframe pair
status.
•
For shared Universal Replicator for Mainframe/ShadowImage for Mainframe volumes, the
Universal Replicator for Mainframe pair status is reported to the host if you query the Universal
Replicator for Mainframe primary data volume or secondary data volume. To obtain the
ShadowImage for Mainframe pair status, query the target volume (T-VOL) of the ShadowImage
for Mainframe pair.
•
ShadowImage for Mainframe supports multiple T-VOLs for each source volume (S-VOL). If you
issue a pair status query to a ShadowImage for Mainframe S-VOL (for example, pairdisplay),
the status for only one ShadowImage for Mainframe pair is reported (the pair with the T-VOL
with the lowest LDEV ID). To obtain the pair status for the ShadowImage for Mainframe pair(s)
with the other T-VOL(s), you must direct the host query to the specific S-VOL using the T-VOL’s
LDEV ID in the host command. The ShadowImage for Mainframe remote console software
displays the port, TID, LUN, LDEV ID, and ShadowImage for Mainframe pair status for all
T-VOLs associated with an S-VOL.
Table 22 Host Pair Status Reporting for Universal Replicator for Mainframe/ShadowImage for
Mainframe Shared Volumes
Pair status reported by the XP disk array
Number of
ShadowImage
for Mainframe
T-VOLs
Number of
Universal
Replicator for
Mainframe
pairs
Simplex
0
0
ShadowImage for Mainframe pair status
1
0
ShadowImage for Mainframe pair status for the pair whose S-VOL has
the lowest LDEV ID
2 or more
0
Universal Replicator for Mainframe pair status
0
1
Universal Replicator for Mainframe pair status
1
1
Universal Replicator for Mainframe pair status
2 or more
1
Table 23 Data Currency of a Shared Universal Replicator for Mainframe/ShadowImage for
Mainframe Volume
ShadowImage for Mainframe pair status
Universal
Replicator for
Mainframe
pair status
Suspended
Resync
Split
Split-Pending
Duplex
Pending
Duplex
Not current
Not current
CURRENT
Not current
Not current
Not current
Pending
Duplex
Not current
Not current
CURRENT
Not current
Not current
Not current
Duplex
Not current
CURRENT
CURRENT
CURRENT
CURRENT
Not current
Suspended
