Table 30 DKC Operation Window Details
Description Item
Changes information in the DKC Operation window.
•
DKC shows information about the remote storage systems and the logical paths.
Port shows information about the ports on the local storage system.
Display
Lists either of the following:
• Remote storage systems
•
Channel adapters on the local storage system and port attributes
Tree
Lists detailed information about one of the following:
• Remote storage systems
•
Logical paths
• Ports on the local storage system
Operation list
Shows changes made in the window before the changes are applied to the storage
systems. When the information in Preview is correct, click Apply to apply the
settings. Preview list
Indicates the operation in progress in the DKC Operation window. Operation
Information on the DKC Operation window will be updated when you do one of the following:
•
Click Apply.
•
Select another tab and then reselect the DKC Operation tab.
•
Click File, Refresh on the menu bar of the Remote Web Console main window.
•
Select Modify mode when you are in view mode.
Viewing Information About Remote Storage Systems
To view information about remote storage systems:
1. Open the DKC Operation window.
2. In the Display box, select DKC. The tree and the list show information about the remote storage
systems.
DKC Operation Window 123
