To open the Usage Monitor window, do either of the following:
•
If Universal Replicator for Mainframe has not been started:
◦
Select Go, Universal Replicator for Mainframe and then Usage Monitor on the menu bar
of the Remote Web Console main window.
Universal Replicator for Mainframe starts and the Usage Monitor window is displayed.
•
If Universal Replicator for Mainframe has already been started:
◦
Select the Usage Monitor tab.
The Usage Monitor window is displayed.
Figure 55 Usage Monitor Window
Table 33 Usage Monitor Window Details
Description
Item
Monitoring status:
•
Enable: Monitoring is on
•
Disable: Monitoring is off When monitoring is stopped, the usage monitor graph
is unavailable.
Monitoring Switch
The data collection interval
Gathering Interval
The most recent data sample time of the data on the graph
Update
The remote I/O statistic information and the status of remote copy monitor
Usage Monitor Graph
History Window
The History window (see
) display the history of operations for data volume
pairs. For example, the window shows the date and time when data volume pairs are created or
released.
