Storing period
Short-Range can be specified.
Selection of monitoring objects
Select monitoring objects in Performance Objects field. The combination of items is shown as
follows.
Item on right side of Monitor
Data field Item on left side of Monitor
Data field Item on right side of Object
field Item on left side of Object
field
None Business Copy (%) None Logical Device*
* Only information on internal volumes is displayed. Information about external volumes, FICON DM volumes, and
virtual volumes such as DP-VOLs, Fast Snap V-VOLs, and Snapshot V-VOLs is not displayed.
Detailed information of resources on top 20 usage rates
Function
You can view resources of the 20 most used MP blades, and the maximum number of blades in
the system is 8. The system puts in order of use 20 MP blades based on rates gathered during the
most recent usage period. You cannot specify a particular period.
Storing period
Only the Short-Range real time monitoring data can be supported.
Selection of monitoring objects
Select monitoring objects in Performance Objects field. The combination of items is shown as
follows.
Item on right side of Monitor
Data field Item on left side of Monitor
Data field Item on right side of Object
field Item on left side of Object
field
None Usage Rate (%) MP Controller
Viewing MP blade resource details
To view the resources assigned to an individual MP blade, click the link to the name of the MP
blade in the right panel of the Monitor window. The MP Properties window lists the 20 most-used
resources by blade name.
