Table 11 Performance management windows and monitoring data saved by the Export Tool
(continued)
Monitoring data
GUI operation
Select Controller from Object list in
Performance Objects field in Monitor
Performance window.
Select Port from Object list in Performance
Objects field in Monitor Performance
window.
Select LUN from Object list in Performance
Objects field in Monitor Performance
window.
Select WWN from Object list in
Performance Objects field in Monitor
Performance window.
Usage Monitor tab in the Cnt Ac-S and Cnt
Ac-S Z window
Usage Monitor tab in the Cnt Ac-J and Cnt
Ac-J Z window
Usage Monitor tab in the Cnt Ac-J and Cnt
Ac-J Z window (continued)
Resource usage and write-pending rate statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be saved to files using the Export Tool. These files contain statistics about resource
usage and write pending rates.
Table 12 Files with resource usage and write pending rate statistics
Data saved in the file
CSV file
ZIP file
Usage rates for parity groups in long range.
PHY_Long_PG.csv
PhyPG_dat.ZIP
Usage rates for parity groups in short range.
PHY_Short_PG.csv
Usage rates for volumes in a parity group in long
range.
PHY_Long_LDEV_x-y.csv
PhyLDEV_dat.ZIP
Usage rates for volumes in a parity group in short
range.
PHY_Short_LDEV_x-y.csv
Usage rates for Business Copy volumes in a parity
group in short range.
PHY_Short_LDEV_SI_x-y.csv
If external storage volumes are mapped to the
volume groups of P9500, this file includes the
PHY_ExG_Response.csv
PhyExG_dat.ZIP
average response time for the volume groups
including external storage volumes (milliseconds).
If external storage volumes are mapped to the
volume groups of P9500, this file includes the
PHY_ExG_Trans.csv
amount of transferred data for volume groups
including external storage volumes (KB/sec).
If external storage volumes are mapped to the
volume groups of P9500, this file includes the
PHY_ExG_Read_Response.csv
average read response time for the volume
