Host bus adapters connected to ports statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be exported to files using the Export Tool. These files contain statistics about host
bus adapters connected to ports.
Table 17 Files with statistics about host bus adapters connected to ports
Data saved in the file
CSV file
ZIP file
The I/O rate (that is, the number of read and write operations per
second) for HBAs that are connected to a port
PortWWN_xx_IOPS.csv
PortWWN_dat.ZIP
The size of data transferred per second (KB/sec) between a port
and the HBAs connected to that port
PortWWN_xx_KBPS.csv
The average response time (microseconds) between a port and
the HBAs connected to that port
PortWWN_xx_Response.csv
Notes:
•
The letters "xx" in CSV filenames indicate a port name. For example, if the filename is PortWWN_1A_IOPS.csv,
the file contains the I/O rate for each host bus adapter connected to the CL1-A port.
•
If files are exported to a Windows system, CSV filenames may end with numbers (for example,
PortWWN_1A_IOPS-1.csv
and PortWWN_1a_IOPS-2.csv).
Volumes (LU) statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be exported to files using the Export Tool. These files contain statistics about
volumes (LUs).
Table 18 Files with statistics about volumes (LUs)
Data saved in the file
CSV file
ZIP file
The number of read and write operations per second
LU_IOPS.csv
LU_dat.ZIP
The size of data transferred per second (KB/sec)
LU_TransRate.csv
The size of read data transferred per second (KB/sec)
LU_Read_TransRate.csv
The size of write data transferred per second (KB/sec)
LU_Write_TransRate.csv
The average read response time (microseconds)
LU_Read_Response.csv
The average write response time (microseconds)
LU_Write_Response.csv
The number of sequential read operations per second
LU_Seq_Read_IOPS.csv
The number of random read operations per second
LU_Rnd_Read_IOPS.csv
The number of sequential write operations per second
LU_Seq_Write_IOPS.csv
The number of random write operations per second
LU_Rnd_Write_IOPS.csv
The read hit ratio in sequential access mode
LU_Seq_Read_Hit.csv
The read hit ratio in random access mode
LU_Rnd_Read_Hit.csv
The write hit ratio in sequential access mode
LU_Seq_Write_Hit.csv
The write hit ratio in random access mode
LU_Rnd_Write_Hit.csv
The number of data transfer operations per second from cache memories
and hard disk drives (for example, LUs)
LU_C2D_Trans.csv
The number of data transfer operations per second from hard disk drives (for
example, LUs) to cache memories in sequential access mode
LU_D2CS_Trans.csv
Exported files
