Table 12 Files with resource usage and write pending rate statistics (continued)
Data saved in the file
CSV file
ZIP file
Usage rates for access paths between disk
adapters and cache memories in long range
PHY_Long_DKA_ESW.csv
Usage rates for access paths between channel
adapters and cache memories in short range
PHY_Short_CHA_ESW.csv
Usage rates for access paths between disk
adapters and cache memories in short range
PHY_Short_DKA_ESW.csv
Usage rates for access paths between MP blades
and cache memories in long range
PHY_Long_MPPCB_ESW.csv
Usage rates for access paths between MP blades
and cache memories in short range
PHY_Short_MPPCB_ESW.csv
Usage rates for access paths between cache
switches and cache memories in long range
PHY_Long_ESW_Cache.csv
Usage rates for access paths between cache
switches and cache memories in short range
PHY_Short_ESW_Cache.csv
Write pending rates in long range in the entire
system
PHY_Long_Write_Pending_Rate.csv
Write pending rates in short range in the entire
system
PHY_Short_Write_Pending_Rate.csv
Usage rates for cache memory in each the entire
system
PHY_Short_Cache_Usage_Rate.csv
Write pending rates in long range in each MP
blade
PHY_Long_Write_Pending_Rate_z.csv
Write pending rates in short range in each MP
blade
PHY_Short_Write_Pending_Rate_z.csv
Usage rates for cache memory in each MP blade
PHY_Short_Cache_Usage_Rate_z.csv
The allocated size of the cache memory in each
MP blade (MB)
PHY_Cache_Allocate_z.csv
This value does not correspond with the total
capacity of cache because the value is same as
the allocated size of the cache memory that is
managed by a processor blade.
Notes:
•
The letters “x-y” in CSV file names indicate a parity group or external volume group.
•
The letter “z” in CSV file names indicate a name of MP blade.
•
Both long range and short range statistics are stored for resource usage and write pending rates.
•
You can select Long-Range or Short-Range from Data Range field in the Monitor Performance window
Parity groups, external volume groups, or V-VOL groups statistics
The following table shows the file names and types of information in the Monitor Performance
window that can be exported to files using the Export Tool. These files contain statistics about parity
groups, external volume groups, or V-VOL groups.
Table 13 Files with statistics about parity groups, external volume groups or V-VOL groups
Data saved in the file
CSV file
ZIP file
Number of read and write operations per second
PG_IOPS.csv
PG_dat.ZIP
Size of data transferred per second (KB/sec)
PG_TransRate.csv
