Description
Item
Monitoring object
ID of the volume, in the following format:
LDKC:CU:LDEV.
LDEV ID
Logical Device
Name of the LDEV. LDEV Name is the
combination of fixed characters and
numbers.
LDEV Name
ID of the parity group.
Parity Group ID
Parity Group
Name of the port.
Port ID
LUN
Name of the host group.
Host Group Name
ID of the LUN.
LUN
ID of the volume, in the following format:
LDKC:CU:LDEV.
LDEV ID
External Storage/Logical Device
Name of the LDEV. LDEV Name is the
combination of fixed characters and
numbers.
LDEV Name
Parity group ID of the external volume.
Parity Group ID
External Storage/Parity Group
ID of a processor blade and processor.
MP Blade ID/MP ID
Controller/MP
ID of a data recovery and reconstruction
processor.
DRR ID
Controller/DRR
ID of a processor blade.
MP Blade ID
Cache
Name of the cache.
Cache
Name of the access path.
Access Path
Access Path
Wizard buttons
These standard buttons are used to set information in and navigate among the monitoring windows.
Description
Item
Check to go to the task window after clicking Apply.
Go to tasks window for status
Click to move to the previous task.
Back
Click to move to the next task.
Next
Click to apply the settings to the storage system.
Apply
Finishes finish the task.
Finish
Cancels the current task and closes this window.
Cancel
Opens the help topic for this window.
Help
Navigation buttons
These standard buttons are used to control the information appearing the monitoring windows.
Description
Item
Filter
•
ON:
•
OFF:
Click to select all pages.
Select All Pages
