Web-Based User Interface
Table 3-7: Bay Information Screen
Field Possible
Values Description
Status Area
Bay Number
Bay number
Server Blade Name
Name of the server blade as specified
with the server blade operating system
Status
OK, Degraded, or Failed
Status of the server blade
Thermal Condition
OK, Warm, Caution, or Critical
Thermal condition of the blade
Enclosure Name
Name of enclosure
For the default enclosure name, see
Appendix E, “Factory Default
Settings.”
Rack Name
Name of the rack
For the default rack name, see
Appendix E, “Factory Default
Settings.”
General Area
Server Blade Type
Product name of the server blade
Server Blade
Installed OS
Operating
system
installed on the
server blade
Spare Number
Spare number of the server blade
Serial Number
Serial number of the server blade
Asset Tag
Asset tag number of the server blade
BIOS version
mm/dd/yyyy
ROM version on the server blade
CPU # Type
Type of processor on the server blade
CPU # Max. Speed
Speed associated with the server
blade processor
Installed RAM
Amount of memory installed on the
server blade
continued
HP ProLiant BL e-Class Integrated Administrator User Guide
3-27
