Web-Based User Interface
Deck Panel
Figure 3-4 illustrates the location of the deck panel.
Figure 3-4: Deck panel of the Web-based user interface
The deck panel displays the areas of information provided by the available screens
under each tab. Information appearing in the deck panel depends on the option
chosen by the user from within the top panel and the left panel.
Enclosure Tab
The Enclosure tab provides access to the following screens:
•
•
•
Enclosure Information
Network Configuration
SNMP Configuration
3-6
