Printer Specifications
Specifications .................................................................................................................................................. 761
Print Area ........................................................................................................................................................ 764
Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply
100–120 V AC (50/60 Hz), 220–240 V
AC (50/60 Hz)
Power consumption
During operation
190 W max.
Sleep mode
100–120 V: 5 W max.
220–240 V: 6 W max.
Off
1 W max. (*1
)
Operating noise (*2
)
During operation
Approx. 52 dB (A) max. (6.8 bels or
less)
Standby
Approx. 35 dB (A) max.
Operating environment
Temperature
15–30°C (59–86°F)
Humidity
10–80%, non-condensing
Dimensions (W × D × H)
Printer only
1,893 Ч 766 Ч 1,144 mm (74.5 Ч 30.2 Ч
45.0 in)
Printer and Stand (including Roll
Holder and Wheeled Output Stack-
er )
1,893 Ч 1,291 Ч 1,144 mm (74.5 Ч 50.8
Ч 45.0 in)
Weight
Printer and Stand (not including the
Printhead and Ink Tank )
Approx. 189 kg (416.7 lb)
Space for installation (W × D × H)
Printer and Wheeled Output Stacker
2,293 Ч 1,837 Ч 1,500 mm (90.3 Ч 72.3
Ч 59.1 in)
*1: The printer uses a trace amount of power even when turned off. To stop all power consumption, turn off the
printer and unplug the power cord.
*2: Calculation based on ISO 7779. Operating conditions: On the Main sheet of the printer driver, Media Type >
Plain Paper, Advanced Settings > Print Priority > Line Drawing/Text, and Print Quality > Standard.
Printing performance
Print method
Bubblejet
Maximum resolution
Printhead
PF-03
Number of nozzles
MBK: 5,120; Others: 2,560 each color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Printer Parts
>
Printer Specifications
>
iPF825
Specifications
9
761
