Back
a. Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
b. Ethernet Port
Connect an Ethernet cable to this port. The lamp is lit if the Ethernet cable is connected correctly and communication is
possible between the computer and printer.
c. USB Port
Connect a USB cable to this port. The printer is compatible with Hi-Speed USB connections.
d. Manual Pocket
Store printer manuals in this pocket.
e. Power Supply Connector
Connect the power cord to this connector.
f. Accessory Pocket
Store assembly tools, Roll Holder attachments, and other items in this pocket.
g. Roll Unit Power Supply Inlet
Connect the Roll Unit power cord to this inlet.
Printer Parts > Printer parts >
iPF825 Back
