Chapter 1 Xserve G5 Overview 19
Four-post brackets
Two rivets on each bracket secure it to the brace and the server’s cover.
Four-post braces
These two long U-shaped pieces support the back of the server and attach it to the rack.
Two-post brackets
These two short L-shaped brackets attach to the sides of the server’s enclosure and to
the rack.
Short-rack brackets
These two brackets attach the back of the server to a short rack, 24 or 26 inches deep.
Mounting template
This straight template helps you install the server’s cover so that it is mounted at a right
angle to each front post of the rack.
Screws and clips for attaching brackets and braces to the rack and server cover
Two sets of screws are provided; one set (English) is size10-32; the other is metric size M5.
Short screws are provided for mounting the system in a two-post rack or a short four-
post rack. Some clips are also included for use with racks that do not have prethreaded
holes. See “Getting Ready to Install” on page 26 for more about the mounting hardware.
