Your cluster node server at a glance – Apple Xserve G5 User Manual
Page 16
16
Chapter 1
Xserve G5 Overview
Your Cluster Node Server at a Glance
Drive module status light
Apple Drive Module bay
On/standby button and light
Built-in Ethernet link light (Port 2)
System identifier button/light
Enclosure lock and status light
Securing thumbscrews (2)
Built-in Ethernet link light (Port 1)
System activity lights
Drive module activity light
FireWire 400 port
