10.2 Specifications
General Operation______________________
Measuring Principle
Hybrid. User-selectable Doppler or Transit Time operating modes.
Fluid Types
Virtually any acoustically conductive fluid.
Transit time mode from 0% to 10% (0 to 100,000 ppm) particulate.
Doppler from 0.02% to 15% (200 to 150,000 ppm) 50 micron particles.
Fluid Velocity Range
0.25 to 30 feet per second (0.07 to 9 meters per second)
Flow Sensitivity
0.001 feet per second (0.0003 meters per second)
Nominal Pipe Sizes
0.5 inch - 100 inch (20mm to 2500mm)
Pipe Liner Materials
Most plastic liners
Pipe Materials
Most metal and plastic pipes.
Accuracy
Shipping Specifications
Carton Dimensions: 21” x 17” x 9-1/2”
Carton Weight: 24 lbs. (10.9 Kg.)
(excluding T-Track mounting fixtures)
Clamp-On Transducers - Model A__________
Housing
NEMA 6P (IP67), Nickel plated aluminum, SS clamps & hardware.
Dimensions: 3.12H x 2.95W x 1.60D in. (79H x 75W x 41D mm)
Weight (excluding cable): 0.8 lb. (0.4 kg.) each
Cable - non-removable
Shielded coaxial RG/U Type: 59. PVC jacket, black. RoHS Compliant
Available lengths: 10ft (3m), 25 ft. (7m), 50 ft. (15m), 100 ft. (30m)
Pipe Surface Temperature
O O O O -20 F to 250 F (-34 C to 121 C)
Clamp-On Transducers - Models D thru K___
Housing
NEMA 6P (IP67), PVDF base with Polypropylene cover.
Dimensions: 3.12H x 2.95W x 1.60D in. (79H x 75W x 41D mm)
Weight (excluding cable): 0.8 lb. (0.4 kg.) each
Cable - field replaceable options A, B, C, D
Shielded coaxial RG/U Type: 59. FEP jacket, black. RoHS Compliant
Connector: thermoplastic locking. NEMA 6P (IP67)
Available lengths: 10ft (3m), 25 ft. (7m), 50 ft. (15m), 100 ft. (30m)
Cable - non-removable options E, F, G, H
Shielded coaxial RG/U Type: 59. FEP jacket, black. RoHS Compliant
Available lengths: 10ft (3m), 25 ft. (7m), 50 ft. (15m), 100 ft. (30m)
Pipe Surface Temperature
O O O O -20 F to 250 F (-34 C to 121 C)
T-Track mounting system - _______________
Housing cover: Heavy gauge 304 stainless steel
Pipe surface mounting V-blocks: Anodized aluminum
Pipe Clamps (1/2” - 4” models): Nylon 6/6
Pipe Clamps (2” - 24” models): 1” x 96” polypropylene strap, SS ratchet
Hardware: stainless steel
SPU (Signal Processing Unit)___________
Enclosure
NEMA 4X (IP66), Powder coated aluminum, SS clamps and hardware.
Dimensions: 11.00H x 8.60W x 5.00D inches (279H x 218W x 127D
mm)
Weight 9.5 lb. (4.3 Kg.)
Mounting
Wall, pipe (vertical or horizontal) or panel mounting. Hardware
included.
Panel opening: 10.63H x 8.10W inches ( 270H x 206W mm)
Panel Depth. Rear: 2.78 inches (71 mm), Front : 2.18 inches (55 mm)
Power Requirements
95-264 VAC 50/60Hz or 15-30 VDC; 30 watts maximum
Operating Temperature
O O O O O O O 14 F to 140 F (-10 C to 60 C) Storage: -40 F to 158 F (-40 C to
O 70 C)
Display
320 x 240 pixel QVGA backlit LCD, UV resistant.
Simultaneous Rate and Total: 10 digit maximum + exponent to E+32
Decimal location configurable to 10 places.
Display Languages
English, Spanish, French or German selectable.
Keypad
Five-button positive action tactile switch keypad.
Security
Programmable master password and individual configuration
passwords.
Display Volume Units
Independently configurable Rate and Total display units in: U.S.
Gallons, ounces, barrels (US liquid), barrels (US oil), cubic ft, acre ft,
Imperial (British) gallons, liter, cubic meter, or user defined “custom”
units.
Rate display in feet or meters per second.
Display Time Units
Seconds, minutes, hours, days.
Display/Output Response Time
Selectable: 0.25, 0.50, 1.0 (default), 2.5, 5.0 seconds.
Flow Rate Display Averaging
Selectable: 0.50, 1.0, 2.5, 5.0 (default), 10.0 seconds.
Data Outputs
! Isolated 4-20 mA output - fully configurable, invertible
! 0-1000 Hz Pulse output - fully configurable, invertible
Data Logging
Date/time stamped flow rate and flow total data in FAT32 file format,
easily imported into Excel. Configurable to trigger on time interval (1-
999,999 sec), rate and/or total set-point values. Over 500,000 log
events possible with included 32MB SD Card. 2,000 logs held in
memory buffer downloadable using Sonic-Pro user software
application.
Process Control
Three independently configurable 10 amp Form C, NO/NC relays.
! Configure to flow rate for high/low/range rate alarm. Programmable
release values enable auto release or manual latching operation.
! Configure to flow total for manual trigger batch operations or
automatically triggered, timed batch operations.
External Communications
Computer connection via RS-232, RS485, USB, Ethernet.
! Includes user communication and configuration application software
! Permits remote internet access through local network set-up
! Remotely access and upload data logging files.
(default setting)
1.0 Seconds
0.5 Seconds
+/-1% of rate > 1 ft/sec +/-0.01 ft/sec < 1 ft/sec
+/-1% of rate > 5 ft/sec +/-0.05 ft/sec < 5 ft/sec
+/-2% of rate > 12 ft/sec +/-0.25 ft/sec < 12 ft/sec
Flow Rate
Averaging Time
Transit Time Accuracy at at Nominal Pipe Sizes
5.0 Seconds
(default setting)
1.0 Seconds
0.5 Seconds +/-2% of rate > 12 ft/sec +/-0.25 ft/sec < 12 ft/sec
Doppler Accuracy at Nominal Pipe Sizes
5.0 Seconds
+/-2% of rate > 8 ft/sec +/-0.20 ft/sec < 8 ft/sec
+/-2% of rate > 5 ft/sec +/-0.10 ft/sec < 5 ft/sec
