Installation and operating instructions BM 70 A/P Page: 81 11/00
Annex E: Table on documentation of device configuration
CHECK LIST PARAMETERS BM 70 A/P.Vers.:.............. Date: ...............
Device No. ..................................................: Comm. No.... :....................... ........................
Location......................................................: ...................... ........................ ........................
Contact person...........................................: Telephone.... ........................ : .......................
Remarks :................................................... ....................... ........................ ........................
........................................................ ....................... ........................ ........................
Menu item....................................................Changed on .... :....................... : .......................:
Fct. Configuration parameters (excerpt)
3.1.1 Tank height ....................................: ...................... :....................... : .......................:
3.1.2 Block distance ...............................: ...................... :....................... : .......................:
3.1.3 Antenna ..........................................: ...................... :....................... : .......................:
3.1.4 Antenna extension.........................: ...................... :....................... : .......................:
3.1.5 Distance piece ...............................: ...................... :....................... : .......................:
3.1.6 Still well / diameter ........................: ...................... :....................... : .......................:
3.1.7 Offset, reference ............................: ...................... :....................... : .......................:
3.1.8 Offset, tank bottom........................: ...................... :....................... : .......................:
3.3.1 Current output, function ...............: ...................... :....................... : .......................:
3.3.2 Current output, range/error...........: ...................... :....................... : .......................:
3.3.3 Min. scale for current ....................: ...................... :....................... : .......................:
3.3.4 max. scale for current....................: ...................... :....................... : .......................:
3.3.5 Baud rate........................................: ...................... :....................... : .......................:
3.3.6 Address ..........................................: ...................... :....................... : .......................:
3.3.7 Protocol..........................................: ...................... :....................... : .......................:
3.5.2 Empty-tank spectrum ....................: ...................... :....................... : .......................:
3.5.3 Time constant ................................: ...................... :....................... : .......................:
3.5.4 Tracking speed ..............................: ...................... :....................... : .......................:
3.5.5 Multiple reflections (Yes/No) .........: ...................... :....................... : .......................:
3.5.6 Block distance detect.(Yes/No) .....: ...................... :....................... : .......................:
3.5.7 Function FTB .................................: ...................... :....................... : .......................:
3.5.8 Epsilon-R .......................................: ...................... :....................... : .......................:
3.5.9 Tank type .......................................: ...................... :....................... : .......................:
3.6.1 Switching output, function ...........: ...................... :....................... : .......................:
3.6.2 Switching output, limit type..........: ...................... :....................... : .......................:
3.6.3 Switching output, threshold .........: ...................... :....................... : .......................:
3.6.4 Switching output, hysteresis ........: ...................... :....................... : .......................:
