KROHNE BM 70 A_P EN - Manual (Page 36)

Installation and operating instructions BM 70 A/P Page: 36 11/00
8.2 Function of the keys
The three keys have the following functions:
→
(Cursor key): - selects the configuration menu,
- branches the menu to the next lower level,
- moves the cursor* to the right to the next column.
↑
(Select key): - branches the menu to the next digit in the same level,
- changes the content (digit, character) at the cursor* position.
↵
(Enter key): - selects the error memory,
- branches the menu to the next higher level,
- stores newly entered parameters,
- executes displayed functions.
* The cursor position is signalled by flashing of the character or selected point at the appropriate place.
To start operator control:
Measuring mode Operator control mode
Please note: When "YES" is set under Fct. 3.4.2 and ENTRY CODE "CodE1 -------"
appears in the display, the
→
key must be pressed.
The 9-keystroke Entry Code1 must then be entered:
Factory setting:
→ → → ↵ ↵ ↵ ↑ ↑ ↑
(each keystroke confirmed in the display by "*".)
To terminate operator control:
Press key
↵
repeatedly until one of the following menus is displayed.
Fct. 1.0 OPERATION, Fct. 2.0 TEST or Fct. 3.0 INSTALL.
↵
Press key ...
New parameters not to be stored
Press
↑
key to display "STORE.NO".
Measuring mode continued with the "old"
parameters after pressing the
↵
key; the
"START" message is shown until a measured
value is determined.
If instead you wish to return to Configuration,
press the
↑
key first until "RETURN" is
displayed, and then the
↵
key.
Store new parameters
Confirm by pressing the
↵
key,
"START" is displayed, and the measuring
mode is continued with the new parameters.
6 2 7
c m
F c t. 1.0
O P E R A T I O N
→
F c t. 3. 0
S T O R E Y E S I N S T A L L .
↵
