8.4 Table of settable functions (Versions 3.00, 3.01, 3.02, 3.03, 4.02, 4.03)
Function (Fct.) Enter range Default value Description
1.0 OPERATION
1.1 DISPLAY
1.1.1 FCT.DISP Options LEVEL
DISTANCE
CONVERSION
REFLECTION
LEVEL Select function of display
(value to be displayed).
1.1.2 UNIT.LENGTH Options m
cm
mm
inch
Ft
PERCENT
BARGRAPH
Meter [m] Select unit for value of length to be displayed
(level/distance).
1.1.3 UNIT. CONV. Options m3
l
US Gal
GB Gal
Ft3
bbl
PERCENT
BARGRAPH
USER UNIT
Cubic meter [m3] Select unit for conversion value to be displayed
("volume table").
2.0 TEST
2.1 HARDWARE
2.1.1 MASTER Special function Tests the hardware of the master.
2.1.2 DISPLAY Special function Tests the hardware of the display.
2.1.3 STATUS Options Module DIS
Module MW
Displays ID-Number and Status Bytes
2.2 CUR.OUTP.I
2.2.1 VALUE I Value display Displays the actual value of the current output.
2.2.2 TEST I Options 2 mA
4 mA
6 mA
8 mA
10 mA
12 mA
14 mA
16 mA
18 mA
20 mA
22 mA
2 mA Output of selected value to the current output.
IMPORTANT !!! With safety inquiry because of direct
access to the current output !!!
(Exi = min. 3.6 mA)
2.3 SW.OUTPUT
2.3.1 TEST S Options OPEN
CLOSED
OPEN Switching output on/off.
IMPORTANT !!! With safety inquiry because of direct
access to the switching output !!!
2.4 FIRMWARE
2.4.1 MASTER Display Displays the firmware version of the master.
2.4.2 DISPLAY Display Displays the firmware version of the display.
3.0 INSTALL.
3.1 BASIS.PARAM
3.1.1 TANKHEIGHT Options, unit m
cm
mm
inch
Ft
Enter
0.50 [m] ... max. tank height
m
10.00 m* / 20.00 m *
To input the tank height.
The tank height is defined as the vertical distance
between the bottom edge of the flange and the tank
bottom.
The unit entered here is also used for all other length
inputs.
3.1.2 BLOCKDIST Enter
0.10 [m] ... tank height
0.50 m * To input the block distance.
The block distance marks the non-measurable range
below the bottom edge of the flange.
3.1.3 ANTENNA Options STANDARD
WAVE STICK
STANDARD * Selection of the antenna type.
(WAVE STICK only for BM 70 A)
3.1.4 ANT.EXTENS. Enter
0.00 [m] ... Tank height
0.00 m * To input the length of the antenna extension.
3.1.5 DIST.PIECE Enter
0 ... 2000 [mm]
0 mm * To input the length of the flange distance piece in [mm]
(high-temperature version = 120 mm).
