Drain Drain Drain Drain
1 Flange + 3/8 NPT
2 Flange + ½ NPT
3 Flange + G 3/8
4 Flange + G ½
A Flange (as per process connection)
Sealing Sealing Sealing Sealing
0 Without
1 Aramid (without asbestos)
2 316L graphite
3 PTFE
Indicator / scale Indicator / scale Indicator / scale Indicator / scale
0 Without indication
1 Flaps / without scale
2 Flaps / m + cm
3 Flaps / feet + inch
4 Flaps / %
Transmitter/Converter position Transmitter/Converter position Transmitter/Converter position Transmitter/Converter position
0 Without
D LT40 (4-20 mA) + display / top of chamber
E LT40 (4-20 mA+HART) + display / top of chamber 1
F LT40 (4-20 mA) / top of chamber
G LT40 (4-20 mA+HART) / top of chamber
H LT40 (FF) / top of chamber
K LT40 (PROFIBUS PA) / top of chamber
N LT40 (4-20 mA) + display / bottom of chamber
P LT40 (4-20 mA+HART) + display / bottom of chamber 1
R LT40 (4-20 mA) / bottom of chamber
S LT40 (4-20 mA+HART) / bottom of chamber
T LT40 (FF) / bottom of chamber
U LT40 (PROFIBUS PA) / bottom of chamber
Transmitter approval Transmitter approval Transmitter approval Transmitter approval
0 Without
1 Ex i
Number of limit switches Number of limit switches Number of limit switches Number of limit switches
0 Without
1 1 switch
2 2 switches
3 3 switches
4 4 switches
5 5 switches
VF42 VF42 VF42 VF42 4 Order code (complete this code on the pages that Order code (complete this code on the pages that Order code (complete this code on the pages that Order code (complete this code on the pages that
follow) follow) follow) follow)
