TECHNICAL DATA
8
71
BM 26 BASIC/ADVANCED
www.krohne.com
10/2012 - 4000347004 - HB BM26 Basic/Adv R04 en
Dimensions in mm
Dimensions in inches
Weights in kg and lb
Liquid
density
[kg/l]
Dimensions [mm]
a
b
C-C
ML
c
d
e
g
k
L
p
q
r
s
Øt
Top lateral /
Bottom axial
process
connections
0.58…
0.7
1
580
2
ML
+580
300
...5
300
3
55.5
4
106
15
74
5
32
113
259
70 42.4
0.7…
0.99
1
400
2
ML
+400
3
55.5
4
106
15
74
5
32
113
259
70 42.4
0.99…
2.0
1
360
2
ML
+360
3
55.5
4
106
15
74
5
32
113
259
70 42.4
1 For more data, refer to "Floats" at the end of this chapter
2 Optional 3/8NPT vent: 228mm. Optional 1/2NPT vent: 228 mm. Optional G1/2 vent: 220 mm. Optional welded OPTIWAVE 7300 transmit-
ter: 542 mm. Optional OPTIFLEX 1300 transmitter with 2 mm single cable probe: 454 mm. Optional flange vent: 328 mm. Optional DN40
flange: 193 mm.
3 EN flange, type B: 135.2 mm. EN flange, type C: 134.7 mm. EN flange, type E: 135.2 mm. Long stud: 130.2 mm. Male thread connection:
58.2 mm.
4 If ambient temperature is -40...-20°C: 85.5 mm (with Plexiglas® cover)
5 Depends on the options selected. Contact your local sales office for more data.
Liquid
density
[lb/ft³]
Dimensions [inches]
a
b
C-C
ML
c
d
e
g
k
L
p
q
r
s
Øt
Top lateral /
Bottom axial
process
connections
36.2…
43.7
1
22.8
2
ML
+22.8
11.
8...
208
3
2.2
4
4.2
0.6
2.9
5
1.3
4.4
10.2
2.8
1.7
43.7…
61.8
1
15.7
2
ML
+15.7
3
2.2
4
4.2
0.6
2.9
5
1.3
4.4
10.2
2.8
1.7
61.8…
124.8
1
14.2
2
ML
+14.2
3
2.2
4
4.2
0.6
2.9
5
1.3
4.4
10.2
2.8
1.7
1 For more data, refer to "Floats" at the end of this chapter
2 Optional 3/8NPT vent: 9.0¨. Optional 1/2NPT vent: 9.0¨. Optional G1/2 vent: 8.6¨. Optional welded OPTIWAVE 7300 transmitter: 21.3¨. Op-
tional OPTIFLEX 1300 transmitter with 0.08¨ single cable probe: 17.9¨. Optional flange vent: 12.9¨. Optional DN40 flange: 7.6¨.
3 EN flange, type B: 5.3¨. EN flange, type C: 5.1¨. EN flange, type E: 5.3¨. Long stud: 5.1¨. Male thread connection: 2.3¨.
4 If ambient temperature is -40...-4°F: 3.4¨ (with Plexiglas® cover)
5 Depends on the options selected. Contact your local sales office for more data.
Weights
Weights for every
additional 100 mm
Weights for every
additional 4 inches
[kg]
[lb]
[kg]
[lb]
Min.: DN15 PN40 flanges
6.7…7.3
1
14.8…16.1
2
0.3
0.7
Max: 1½¨ 600 lb flanges
9.2…9.8
1
20.3…21.6
2
0.3
0.7
Limit switch
0.085
0.2
1 When L=500 mm - if liquid density is low, then weight is higher
2 When L=20¨ - if liquid density is low, then weight is higher
