Operation – KROHNE UFC 400 FOUNDATION FIELDBUS EN User Manual
Page 54
4
OPERATION
54
UFC 400
www.krohne.com
05/2013 - 4002813701 - AD FF UFC 400 R01 en
SENSOR_DSP_
SENSOR_DSP_
SENSOR_DSP_
SENSOR_DSP_
INFO
INFO
INFO
INFO
Sensor DSP
Displays information of the sensor DSP software. Displays the
ID of the DSP on the FrontEnd (Fct. B3.4.2, C1.6.2).
-
IDENT_NUMBER
ID-No. Board
R
ID No. of the circuit board.
-
SOFTWARE_VER
Software version
R
Software version
-
PRODUCTION_
DATE
Production date
R
Production date
-
USER_INTERFACE
USER_INTERFACE
USER_INTERFACE
USER_INTERFACE
SW.REV.UIS
Displays information of User Interface (Fct. B3.6).
-
IDENT_NUMBER
ID-No. Board
R
ID No. of the circuit board.
-
SOFTWARE_VER
Software version
R
Software version
-
PRODUCTION_
DATE
Production date
R
Production date
-
TRANSDUCER_
TRANSDUCER_
TRANSDUCER_
TRANSDUCER_
DIRECTORY
DIRECTORY
DIRECTORY
DIRECTORY
Transducer
Directory Entry
A directory that specifies the number and starting indices of
the data collections in the transducer block.
0
TRANSDUCER_
TRANSDUCER_
TRANSDUCER_
TRANSDUCER_
TYPE
TYPE
TYPE
TYPE
Transducer Type
R
Identifies the transducer that follows.
Other
XD_ERROR
XD_ERROR
XD_ERROR
XD_ERROR
Transducer Error
One of the transducer error codes defined in the FF
Transducer Specifications in section "4.7 Block Alarm
Subcodes".
Uninitialized
Settings:
•
16: Unspecified error
•
17: General error
•
18: Calibration error
•
19: Configuration error
•
20: Electronics Failure
•
21: Mechanical Failure
•
22: I/O Failure
•
23: Data Integrity Error
•
24: Software Error
•
25: Algorithm Error
V_NO_SENSOR
V_NO_SENSOR
V_NO_SENSOR
V_NO_SENSOR
V no. sensor
R
Displays the order number of the measuring sensor (Fct.
C1.6.6).
Parameter
Parameter
Parameter
Parameter
DD name
Access
Description and settings
Initial Value
