BOP HIPWR 031014
1-17
1.9 SAFETY
Service must be referred to authorized personnel. Using the power supply in a manner not
specified by Kepco. Inc. may impair the protection provided by the power supply. Observe all
safety precautions noted throughout this manual (see listing on page E, preceding the Table of
Contents). Table 1-5 lists symbols used on the power supply or in this manual where applicable.
IDC 6-pin connector Mating connector for RS-232 PORT, connector A1J5 and PRO-
TECTION EXT. PORT, connector A2A5J7 142-0536
(Amphenol 5-555176-3)
IDC 8-pin plug Mating connector for PAR/SER PROTECT PORT (IN and
OUT) connectors. 142-0535
(Amphenol 5-557961-2)
Slides Allows easy withdrawal of unit from rack (see Figure 1-2).
(Model CS 04 includes slides, brackets, all mounting hardware
and installation instructions.)
CS 04
Heat Sink Provides adequate cooling for calibration sense resistors. 136-0451
Terminal Cover Protects against contact with output and barrier strip terminals.
Install using the two existing screws (adjacent to two ground
terminals) securing rear panel to chassis. Particularly recom-
mended for 72V and 100V models for safety purposes. Consult
factory for parallel/series configurations. 129-0423
TABLE 1-5. SAFETY SYMBOLS
SYMBOL Meaning
WARNING! RISK OF ELECTRIC SHOCK!
CAUTION: REFER TO REFERENCED PROCEDURE.
WARNING
INDICATES THE POSSIBILITY OF BODILY INJURY
OR DEATH.
CAUTION
INDICATES THE POSSIBILITY OF EQUIPMENT
DAMAGE.
TABLE 1-4. ACCESSORIES (CONTINUED)
ITEM FUNCTION PART NUMBER
!
