1.4

LOCAL CONTROL

Either the front panel keypad or the adjust control can set and adjust output voltage and current
under local control. The display provides a digital display of output voltage and current as well
as a pictorial display of real-time analog voltage and current meters.

The keypad includes five function keys which provide access to the menu-driven functions of
the unit. The menu screens provide access to save the unit’s settings, recall previously saved
settings, configure or execute a waveform, display references or configure the unit by setting
GPIB address, Serial protocols, maximum acceptable voltage and current, etc. (see PAR. 3.3
for details on local control).

Context-sensitive help screens are available by pressing the HELP key. Actual output voltage
and current displays are available while the help screens are displayed.

1.5

REMOTE CONTROL

The BOP Power Supply can be remotely controlled directly via either the IEEE 488.2 (GPIB)
bus (see PARs. 3.5 and 3.5.4) or RS232C (see PAR.3.5.6) interface using SCPI commands
(see and Appendix A and B). Most features available in local mode can also be accessed
remotely via the digital interface. The unit can be controlled with a VISA (Virtual Instrumentation
Software Architecture) driver to facilitate remote programming of the BOP Power Supply (see
PAR. 3.5.5). The VISA driver is an interface written in standard C language which adds the
proper SCPI syntax to commands sent to the BOP.

Programmed settings for main and protection channels are not displayed on the front panel
when in remote mode; these settings can be displayed if needed by setting Remote Debug to
ON (see PAR 3.2.5.2), however this slows power supply response.

PHYSICAL CHARACTERISTICS (Continued)

Connections

Source power

3-pin IEC connector

Load connections

Nickel-plated copper bus bars

With 1/4-20 threaded standoff.

Sensing Output

Terminal Block

7-pin terminal block

Default: 3 links installed for local sensing and
ground network connected.

Analog I/O control

port

15-pin D female

See Figure 2-1, Table 2-10

PAR/SER CTRL IN

port

8-pin mini DIN connector

See Figure 2-1, Table 2-7

PAR/SER CTRL OUT

port

4-pin mini DIN connector

See Figure 2-1, Table 2-6

PAR/SER PROT IN

port

8-pin phone jack

See Figure 2-1, Table 2-8

PAR/SER PROT OUT

port

8-pin phone jack

See Figure 2-1, Table 2-9

EXT PROT port

6-pin phone jack

See Table 2-4

Primary digital port

24-pin GPIB connector

IEEE 488 port - See Table 2-11

Secondary digital

ports

6-pin phone jack

RS 232 port - See Table 2-5

5-pin mini DIN female connector

IEEE 1118 port - See Table 2-2

External Trigger

4-pin stereo audio phone jack

See Table 2-3

TABLE 1-2. BOP GENERAL SPECIFICATIONS (Continued)

SPECIFICATION

RATING/DESCRIPTION

CONDITION
