Manual No. 4801-3001 Rev 7-08

Secondary Sensing System Expansion

35 of 46

13.8 S

3

PowerTrak Override Settings and Wiring
























































PowerTrak

Inset A

Vent Override

for Fail-Safe

Action

INLET

MODE

Vent Override

Cool 1

Tunnel Override

Cool 3

Vents & Tunnel Will Wire The Same

NOTE: If curtain is setup to pull curtain up to open, then reverse wires

connected to 'Open' and 'Close' terminals.

Inset B

PowerTrak

Inset B

PowerTrak

Inset B

Inset A

Vent Override

for Normal

Action

Refer to

Section 6.1

P5 & P6

Settings

S

3

Expansion PCB179

Tunnel Override

Inset A
Vents Override

NOTE: If
connecting the
Back-Up to a relay
box instead of
PowerTrak, Cut
and discard the
four components
shown.
