Manual No. 4801-3001 Rev 7-08

Secondary Sensing System Expansion

32 of 46

P 1- 9 G eneral Param eters

P1 = Temperat ure Units

C = Celsiu s

P2 = In divid ual Alarm Temp erature L imit s

F = Fah renheit

Yes = Temperatu re Limits Set Individually
No = T emperature Limits Set Identical

P3 = B ack-Up Timer Percen tag e
P4 = B ack-Up St age O n Delay
P4 = B ack-Up St age O n Delay

P 40-49 Hired -Hand Netw ork

P40 = HH

Netw or k Add ress

NET

P41 = Soft ware Version Number
P42 = Con tr oller Setup
P43 = L ocal Network Enable

No = No t Con nect ed ( Stand- Alon e)

Yes = Con nected (EV Netwo rk)

P 60-69 Alarm Fun ctio ns

P62 = Cycle Pressure Alarm

ON = Enabled
OFF = Disab led

P63 = Minimum Vent Cycle Time (Min utes)

PS Sensor Calibration

PS1 = Sen sor 1 Calibration
PS2 = Sen sor 2 Calibration
PS3 = Sen sor 3 Calibration

Evolution S

3

16 Stage

Expansion Module

Evolution

Controller

NOTE: Run power cables
including earth ground from
each cabinet to a common
AC junction box. Do NOT
run AC power and ground
between cabinets.

Inset A

(AC Input on S

3

PCB 184)

WARNING!

Keep High Voltage (Or AC) Separate

From Low Voltage Wires!
