D IAGRAMAS DE CONEXIÓN Página 23/115
5.4 GEO S12 / CD18 / NX242-ES4 (Modo pasivo estéreo)
AMPLIFIER 1
AMPLIFIER 2
GEOS12
LEFT STEREO
IN
TO AMPLIFIERS
STEREO
FROM AMPLIFIERS
GEOS12 LEFT GEOS12 RIGHT
+ 4 - + 3-
STEREO
GEOS12 STEREO MODE
WITH CD18 MONO
SUB
FRONT SUB
REAR
Speakon 4
SUB REAR
SUB FRONT
+ 2 - + 1 -
1 (+) / 1 (-) REAR
2 (+) / 2 (-) FRONT
Speakon 4 Speakon 4
Speakon 4 Speakon 4
1 (+) / 1 (-) N.C.
2 (+) / 2 (-) FULL RANGE
GEOS12
RIGHT
