Nexo GEO S12 User Manual
Page 21
D
IAGRAMAS
DE CONEXIÓN
Página
21/115
5.2 GEO S12 / NX242-ES4 (Modo pasivo con 4 canales)
AMPLIFIER 1
AMPLIFIER 2
GEOS12
#3
IN
1
TO AMPLIFIERS
STEREO
FROM AMPLIFIERS
GEOS12
#3
GEOS12
#4
+ 4 - + 3-
STEREO
GEOS12
4 CHANNELS
+ 2 - + 1 -
Speakon 4
Speakon 4
Speakon 4
1 (+) / 1 (-) N.C.
2 (+) / 2 (-) FULL RANGE
GEOS12
#4
Speakon 4
Speakon 4
Speakon 4
Speakon 4
Speakon 4
GEOS12
#1
GEOS12
#2
IN
2
GEOS12
#1
GEOS12
#2
