74 8LS User’s Guide
Setup
Test Output
Use this menu to select one of the 30 digital outputs for manual
operation.
Selectable values: 1-30.
Digital Output Test
Use this menu to toggle the state of a digital output between On and Off.
Selectable values: On, Off.
NOTE
Before leaving this menu, turn Off all the outputs
you have turned On.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
TEST OUT
NR = 1
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
DIG OUT
NR01? OFF
