Appendix A: Ramp Soak
8LS User’s Guide 93
Editing the Ready Setpoint
When you assign a profile to a loop, the profile doesn’t start
immediately; instead, it goes to the ready segment (segment 0) and stays
there until you put the profile in Start mode.
You can set a setpoint, assign events, and set event states for the ready
segment. Use this menu to set the ready segment setpoint.
Selectable Values: -999 to 9999, or Off.
Editing the Ready Event States
Use this menu to set the ready state for all outputs that are not used for
control. When you assign a profile, the controller starts the ready
segment: it goes to the ready setpoint and puts all the outputs in the
ready state you set here. The outputs stay in the ready state until the end
of segment 1, when segment 1’s events become active.
When you press NO, you will advance to the next menu. If you press
YES, this menu appears:
Selectable Values: On or Off.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A READY
SP? OFF
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A READY
EVENTS?
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A READY
DO01?OFF
