Appendix A: Ramp Soak
8LS User’s Guide 97
Assigning an Input to a Trigger
This menu appears only if you answered YES to the Edit Segment
Triggers menu. Use it to assign one of the controller’s eight digital
inputs to a segment trigger. You can assign any digital input to ant
trigger. You can also assign the same digital input to multiple triggers.
Selectable Values: 1-12, or No (no input assigned). Setting a trigger to
No disables it.
Changing a Trigger’s True State
Use this menu to toggle a trigger’s true state between On and Off. This
menu appears only if you answered YES to the Edit Segment triggers
menu.
Selectable Values: Off or On.
Latching or Unlatching a Trigger
Use this menu to make a trigger latched or unlatched.
•
A latched trigger is checked once, at the beginning of a segment.
•
An unlatched trigger is checked constantly while a segment is run-
ning. If an unlatched trigger becomes false, the segment timer stops
and the loop goes into trigger wait state.
Selectable Values: N (No: unlatched), Y (Yes: latched).
1
2
3
4
5
6
7
8
LOOP
PROCESS
UNITS
ALARM
SETPOINT
STATUS OUTPUT%
A S01TR1
DIN? NO
1
2
3
4
5
6
7
8
LOOP
PROCESS
UNITS
ALARM
SETPOINT
STATUS OUTPUT%
A S01TR1
DI03?OFF
1
2
3
4
5
6
7
8
LOOP
PROCESS
UNITS
ALARM
SETPOINT
STATUS OUTPUT%
A S01TR1
LATCH? N
