92 8LS User’s Guide
Appendix A: Ramp Soak
Copying the Setup from Another Profile
Use this menu to setup similar profiles quickly, by copying a profile to
another one.
Selectable Values: A to H.
Editing the Tolerance Alarm Time
Use this menu to set a tolerance time that applies to the entire profile.
When the segment goes out of tolerance,
• The segment goes into tolerance hold.
• The segment timer holds.
• The loop’s single loop display shows TOHO (Tolerance Hold).
When the segment has been out of tolerance for more than the tolerance
alarm time,
• The controller goes into tolerance alarm.
• The tolerance timer resets.
You must acknowledge the tolerance alarm by pressing the ALARM
ACK key before you can do any other editing.
Selectable Values: 0:00 to 99:59 (minutes or hours, depending on the
time base setting).
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
R/S PRO
COPY? H
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A OUTTOL
T? 1:00
