Setup Alarms
The Setup Alarms main menu lets you access menus which change the
alarm functions for the selected loop.
You can edit these parameters:
• High process alarm
• Deviation band alarm
• Low process alarm
• Alarm Deadband
The Setup Alarms main menu looks like this:
Answering Yes to this prompt, gets you into the Alarms submenus.
Below is the setup alarms menu tree. Notice the default values inside the
boxes.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
1 SETUP
ALARMS?
1 Alarms
HP? 1000
1 Setup
Alarms?
1 HI Pro
Outpn? 0
1 Alarms
HP? Off
1 Alarms
Dev? 10
1 Alarms
Dev? Off
1 Hi Dev
Outpn? 0
1 Lo Dev
Outpn? 0
1 Alarms
Lp? 0
1 Alarms
Lp? Off
1 Lo Pro
Outpn? 0
1 Alarms
Dbd? 2
1 Alarm
Dly? 0s
