66 8LS User’s Guide
Setup
Heat Output
Use this menu to select the Terminal Block or the Flat Ribbon for the
heat output termination. The heat output is usually defaulted to the
screw terminals of TB2, while the cool output is on the 50 pin flat
ribbon connections of P10. However, you can switch the outputs, so
heat is switched to the flat ribbon output, and cool--to the screw
terminals of TB2.
Selectable values: Term Blk or Flat Rib.
NOTE
The analog output is not available on the ribbon
cable, and the DZC is not available on the screw
terminals.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
1 HT OUT?
TERM BLK
