Appendix B: 8LS-CP
8LS User’s Guide 115
CO+CO2% and % of Hydrogen
Upon selecting CP as the input type, the following menu is available.
Use it to adjust the amount of CO+CO2% in the atmosphere.
Selectable Range: 1-30%.
Upon selecting DP as the input type, the following menu is available.
Use it to adjust the amount of Hydrogen in the atmosphere.
Selectable Range: 1-100%.
Engineering Units
The engineering units of the carbon loop can be edited only for the
Dewpoint type. The engineering units for CP and MV are fixed: "%CP"
for CP and "MV" for MV.
Upon selecting the DP type and following the Hydrogen menu, the next
menu is available. Use it to select if the reading is in ºF or ºC.
Selectable Values: F or C.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
2 CO%
?20
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
2 H%
? 40
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
2 INPUTS
UNIT? ºF
