Appendix A: Ramp Soak
8LS User’s Guide 103
How many times has it cycled?
From Single Loop display, press the RAMP/SOAK key twice. The next
menu will appear. This menu displays the number of times the profile
has run out of the total number of cycles.
Holding a Profile or Continuing from Hold
Use the profile mode menu to hold a profile or continue from Hold. The
next table shows the available modes.
Holding a profile
In Hold mode, all loop parameters stay at their current settings until you
change the mode or reset the profile. To put a profile in hold, follow
these steps:
• Press RAMP/SOAK key repeatedly until you see the R/S mode
menu.
• While the profile is running, the only mode you will be able select is
Hold.
• Press YES to hold the profile, and then ENTER to advance to the
next menu.
Current
Mode
Available
Mode
Description
Start Run Begin running the assigned profile.
Hold Cont Continue from user-selected hold. Profile runs
from the point when you put the profile in Hold
mode. (You cannot continue from a tolerance
hold or a trigger wait.)
After you choose this mode, the controller
switches back to Run mode.
Run Hold Hold the profile.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
1A00/20S
CYC 1/1
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
1A00/20S
SET?HOLD
