96 8LS User’s Guide
Appendix A: Ramp Soak
Editing Event Outputs
This menu appears only if you answered YES to the previous menu. Use
it to assign a digital output to each event. Assign digital outputs that are
not being used for PID control.
Selectable Values: 1-30, except those IN USE, or No (no event).
Changing Event States
Use this menu to assign an output state to each event: On (High) or Off
(Low). When the event occurs, the output goes to the state you assign
here.
Selectable Values: Off (Low) or On (High).
Editing Segment Triggers
Each segment has two triggers (digital inputs). One of these triggers
must be true before the segment can begin. If a segment times out and at
least one of the next segment’s triggers is not true, the profile goes into
trigger wait state.
Use this menu to edit triggers for the current segment.
Selectable Values: YES (to edit triggers of current segment), or NO (to
advance to the Edit Segment Tolerance menu).
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A S01EV1
DOUT?NO
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A S01EV1
DO01?OFF
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
A SEG 01
TRIGGRS?
