100 8LS User’s Guide
Appendix A: Ramp Soak
Assigning a profile the first time
To assign a profile to a loop that doesn’t have a profile, follow these
steps:
1. In Single Loop display, switch to the loop you want to edit.
2. Press the RAMP/SOAK key. The assigning menu appears. (See menu
in previous page)
3. Choose one of the available profiles and press ENTER.
4. Press BACK if you wish to return to Single Loop display without sav-
ing any changes.
Assigning a different profile
To assign a new profile to a loop that already has one assigned, follow
these steps:
1. Press the RAMP/SOAK key three times.
2. Press the NO key. You will see the Reset Profile menu.
3. Press YES, then ENTER, to reset the profile. You will see the Assign
Profile menu. (See previous page.)
4. Choose one of the available profiles and press ENTER.
5. Press BACK if you wish to return to Single Loop display without sav-
ing any changes.
Running a Profile
When you assign a profile, it does not start running immediately;
instead, the loop enters the Ready segment (segment 0). Use this menu
to start a profile (put it in Start mode).
Starting a profile
You can start a profile only when it’s in the Ready segment.
1. Press the RAMP/SOAK key repeatedly until you see the Ramp/Soak
mode menu.
2. While the profile is in Ready segment, the only mode available is the
Run mode.
3. Press YES to start the profile, and then ENTER to advance to the next
menu.
1 2 3 4 5 6 7 8
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUTPUT%
1A00/20S
SET? RUN
