AFL2-12A-HM65 Series Panel PC
Page 88

IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4

IO=2F8h;
IRQ=3, 4
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4
6.3.6 H/W Monitor
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+64 C
SYS Temperature :+29 C
CPU FAN Speed :4643 RPM
VCC3V :+3.296 V
+Vcc_core :+1.064 V
+V5S :+5.067 V
+V12S :+11.968 V
+1.5V :+1.608 V
VSB3V :+3.296 V
VBAT :+3.168 V
5VSB :+5.112 V
> FAN 1 Configuration
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
 PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o CPU Fan Speed
