AFL2-12A-HM65 Series Panel PC

Page 60

Pin RS-422

RS-485

1 TX-

DATA-

2 TX+

DATA+

3 RX+

4 RX-

Table 4-3: DB-9 Connector Pinouts

4.9.4 USB Device Connection

NOTE:

User must install the USB 3.0 driver before connecting a USB device to

the system or else the system may not recognize the connected

device.

There are two USB 2.0 connectors and two USB 3.0 connectors. All connectors are

located on the bottom panel of the AFL2-12A-HM65. To connect a USB device, please

follow the instructions below.

Step 1:

Locate the USB connectors. The locations of the USB connectors are shown

in Chapter 2.

Step 2:

Align the connectors. Align the USB device connector with one of the

connectors on the bottom panel. See Figure 4-22.
